DSC MAXSYS: PC4116 16 Zone Hardwired Expander

Stock Code:
14440
POA

Description

DSC MAXSYS PC4116 16 Zone Hardwired Expander

PC4116 adds 16 hardwired zones

Specification:
• Zone supervision: Zones can be NC with no EOLR, NO/NC with single EOLR or NC with double EOLR (5600ohm resistors)
• 30 programmable zone types & 8 zone options
• VAUX output : 12VDC, 250mA max. from Combus
• Connection for external tamper… supervised by system
• Connect up to 1,000' (305m) from control panel via COMBUS
• Operating environment - 32 to 122°F (0 to 50°C) - 90% RH non-condensing
• Current draw …30mA (from Combus) plus power required for VAUX output if used

See specification sheet below.
Please sign in to your SWL account to access installer manual.
