SWL NYLON Roller Door Reed Switch: Heavy Duty, 62mm Gap, N/C, 100cm Armoured Fly
Description
SWL ETP Slimline Anti-Corrosion Roller Door Reed Switch c/w Armoured 0.5m Fly
If you didn't already know: Nylon provides a high amount of insulation and very high resistance to corrosion. Compared to aluminum, another material heavily used in reed switches - nylon is lighter, stronger and offers higher wear resistance.
Do it right, fit it once. Avoid corrosion-related falses.
Complies to BS EN 50131 - Grade: 2* Security device, tamper protection
Environmental Class: 3 Weather Proof*
Features:
* Robust Anti Corrosion ETP (Engineered Thermo Plastic)
* Slim Line (14mm height)
* 1m Armoured Sleeving
* 62mm Operating Gap
* Dimensions: 101mm (L) x 14mm (H) x 42mm (W)
* The armoured sleeving is 410 Stainless Steel, which is designed to resist corrosion in mild atmospheres, steam, and many mild chemical environments.
WIRING:
Reed Switch: White/ white
Tamper Loop: Red/ Red
See specification sheet below.
